neue Parameter
Men.Punkt Eigenschaft Bereich Parameter
1; HF1RXG RX GAIN 1.8MHz 100
2; HF2RXG RX GAIN 7MHz 90
3; HF3RXG RX GAIN 21MHz 100
4; 50MRXG RX GAIN 50MHz 75
5; VHFRXG RX GAIN 144MHz 100
6; UHFRXG RX GAIN 430MHz 110
7; SSB-S9 SSB S-Meter S9 70
8; SSB-FS SSB S-Meter FS 59
9; FM-S9 FM S-Meter S9 76
10 ;FM-FS FM S-Meter FS 109
11; DISC-L FM Center Meter 35
12; DISC-H FM Center Meter 69
13 ;FM-TH1 FM Squelch 50
14; FM-TH2 FM Squelch 82
15; FM-TI1 FM Squelch 14
16; FM-TI2 FM Squelch 14
17; VCC Power Supply Voltage 138
18; HF1-IC Over-current Protect1.8MHz 135
19; HF2-IC Over-current Protect 7MHz 140
20; HF3-IC Over-current Protect 21MHz 140
21; 50M-IC Over-current Protect 50MHz 113
22; VHF-IC Over-current Protect144MHz 126
23; UHF-IC Over-current Protect430MHz 113
24; HF1 HI RF Power HI 1.8MHz 160
25; HF1-L3 RF Power L3 1.8MHz 90
26; HF1-L2 RF Power L2 1.8MHz 32
27; HF1-L1 RF Power L1 1.8MHz 10
28; HF2-HI RF Power HI 7MHz 190
29; HF2-L3 RF Power L3 7MHz; 105
30; HF2-L2 RF Power L2 7MHz 50
31; HF2-L1 RF Power L1 7MHz 10
32; HF3-HI RF Power HI 21MHz 190
33; HF3-L3 RF Power L3 21MHz 100
34; HF3-L2 RF Power L2 21MH 45
35; HF3-L1 RF Power L1 21MHz 10
36; 50M-HI RF Power HI 50MHz 150
37; 50M-L3 RF Power L3 50MHz 80
38; 50M-L2 RF Power L2 50MHz 23
39; 50M-L1 RF Power L1 50MHz 5
40; VHF-HI RF Power HI 144MHz 100
41; VHF-L3 RF Power L3 144MHz 66
42; VHF-L2 RF Power L2 144MHz 20
43; VHF-L1 RF Power L1 144MHz; 5
44; UHF-HI RF Power HI 430MHz 103
45; UHF-L3 RF Power L3 430MHz 68
46; UHF-L2 RF Power L2 430MHz 21
47; UHF-L1 RF Power L1 430MHz 9
48; HF1TXG TX Gain 1.8MHz 100
49; HF2TXG TX Gain 7MHz 100
50; HF3TXG TX Gain 21MHz 100
51; 50MTXG TX Gain 50MHz 90
52; VHFTXG TX Gain 144MHz 85
53; UHFTXG TX Gain 430MHz 85
54; HF1POM Power Meter 1.8MHz 50
55; HF2POM Power Meter 7MHz 50
56; HF3POM Power Meter 21MHz 50
57; 50MPOM Power Meter 50MHz 50
58; VHFPOM Power Meter 144MHz 50
59; UHFPOM Power Meter 430MHz 45
60; ALC1-M AL ;Meter 204
61; ALC-M ALC Meter 125
62; HF1-RV Reverse ALC 1.8MHz 13
63; HF2-RV Reverse;ALC 7MHz 11
64; HF3-RV Reverse;ALC 21MHz 21
65; 50M-RV Reverse;ALC 50MHz 15
66; VHF-RV Reverse;ALC 144MHz 7
67; UHF-RV Reverse;ALC 430MHz 28
68; CW-CAR Carrier Level CW 252
69; AM-CAR Carrier Level AM 210
70; DEV- W FM;Modulation 211
71; DEV- N FM Modulation 103
72; M-MTR FM Modulation 188
73; CTCSS FM Modulation 151
74; DCS FM Modulation 129
75; LSB-CP SSB Carrier Point -19
76; USB-CP SSB Carrier Point -20
|
|
|
